ABB IMFEC12_Xiamen XingRuiJia Import and Export CO,LTD

Model：ABB IMFEC12

Brand: ABB
Price range (USD): 100-20000
Country: Switzerland
Parameter: Accuracy: Class 1 accuracy (high-precision measurement).
Communication Protocols: Supports RS485, Modbus-RTU, etc.
Input/Output: Input signal types (4-20mA, 1-5V), resolution, accuracy (±0.1% full scale), etc.
Operating Environment: Operating temperature range (-40°C to +70°C), protection rating (IP65/IP20), etc.

ABB IMFEC12

1. Overview

The ABB IMFEC12 is a compact single-phase electronic electricity meter, specifically designed for residential and small commercial applications. It is used to accurately measure and monitor power consumption in single-phase circuits. Its main functions include high-precision measurement, support for communication protocols (such as RS485 and Modbus-RTU), a liquid crystal display (LCD) that shows energy consumption and parameters (e.g., current, voltage, power factor), and load profile storage to optimize energy usage. Some materials mention that it can also be used as an analog input module in industrial automation systems, but there are different descriptions (e.g., regarding the analog input module function as referenced).

2. Parameters

Accuracy: Class 1 accuracy (high-precision measurement).
Communication Protocols: Supports RS485, Modbus-RTU, etc.
Input/Output: Input signal types (4-20mA, 1-5V), resolution, accuracy (±0.1% full scale), etc.
Operating Environment: Operating temperature range (-40°C to +70°C), protection rating (IP65/IP20), etc.

3. Product Features

High Precision and Reliability: High-precision measurement, anti-interference capability (e.g., DIN 3235 Class 3).
Communication and Integration: Supports multiple communication protocols (RS485, Modbus RTU), and is easy to integrate into energy management systems or industrial control systems.
User Interface: An LCD displays energy consumption and parameters.
Function Expansion: Load profile storage, multi-channel input.

4. Structure and Composition

Modular Design: DIN rail mounting, plug-in terminal blocks.
Materials and Protection: Aluminum alloy housing, IP protection rating (IP20/IP65).
Structural Details: Dimensions, weight, wiring method (e.g., plug-in terminal blocks).

5. Application Fields

Residential and Commercial: Used as a single-phase electricity meter for residential and small commercial applications.
Industrial Sector: Industrial automation (e.g., process control, manufacturing), energy management, intelligent logistics, new energy fields.
Others: Industrial automation control systems, robot control, motion control, etc.

6. Installation and Maintenance

Installation: Supports wall-mounted installation and DIN rail mounting; installation guidelines (e.g., wiring, protection rating) must be followed.
Maintenance: Regular inspection, cleaning, fault diagnosis (e.g., remote diagnosis).
Maintenance Recommendations: Follow the operation manual and conduct regular maintenance to ensure long-term reliability.
