Model：ABB IMSED01

Brand: ABB
Price range (USD): 100-20000
Country: Switzerland
Parameter: Input Voltage: 24VDC or 48VDC
Number of Channels: 16 digital input channels
Communication Interface: RS-232-C and SCSI communication ports
Power Requirement: 415 mA +5 V DC, with a typical value of 2.08 W
Operating Temperature: -40°C to +70°C
Dimensions: 120mm × 70mm × 35mm
Protection Class: IP20

ABB IMSED01

1. General Description

The ABB IMSED01 is a high-performance digital input module specifically designed for industrial automation applications. It belongs to the Symphony Plus I/O HR series and is compatible with the Symphony Plus Process Leitsystem (PLS) controller. This module features 16 digital input channels, where each channel can accept voltage signals of 24VDC or 48VDC. It supports "high-level" or "low-level" configuration as well as filtering options. Equipped with LED indicators, the module is used to display the status of each channel. It supports DIN rail mounting, facilitating installation in control cabinets, and communicates with the PLS controller via the HR bus.

2. Parameters

Input Voltage: 24VDC or 48VDC
Number of Channels: 16 digital input channels
Communication Interface: RS-232-C and SCSI communication ports
Power Requirement: 415 mA +5 V DC, with a typical value of 2.08 W
Operating Temperature: -40°C to +70°C
Dimensions: 120mm × 70mm × 35mm
Protection Class: IP20

3. Product Features

High Reliability: Suitable for industrial environments, with high reliability and stability.
Flexibility: Supports multiple configuration options to meet different application requirements.
Modular Design: Enhances the maintainability and adaptability of the system.
Fast Response: Response time is less than 1 millisecond.
Diagnostic Function: Provides fault detection and recovery functions for easy maintenance.

4. Structure and Composition

Modular Design: Adopts a modular design for easy installation and maintenance.
Mounting Method: Supports DIN rail mounting, making it convenient to install in control cabinets.
Communication Interface: Supports RS-232-C and SCSI communication ports.
Power Supply: Built-in power module that supports multiple power inputs.

5. Application Fields

Industrial Automation: Widely used in industrial automation systems, such as production lines, robot control, and sensor control.
Power Systems: Used for monitoring and control of power systems.
Manufacturing Industry: Applied in process control and equipment monitoring in the manufacturing industry.
Building Automation: Utilized in systems like lighting, heating, and ventilation within building automation systems.

6. Installation and Maintenance

Installation: The module adopts a compact design, allowing easy installation in existing power distribution cabinets. It supports multiple installation methods, such as wall-mounted or horizontal installation.
Maintenance: It has excellent anti-interference performance, making it suitable for complex industrial environments. The internal storage space is sufficient, facilitating long-term operation data recording.
Programming: Supports multiple programming languages, such as STL, Ladder, and Function, enabling users to customize according to specific needs.
After-Sales Service: Provides a 12-month warranty period, equipped with professional after-sales support and fast delivery service.
