ABB IMDSO14_Xiamen XingRuiJia Import and Export CO,LTD

Model：ABB IMDSO14

Brand: ABB
Price range (USD): 100-20000
Country: Switzerland
Parameter: Operating Voltage: 220V AC
Output Frequency: 50Hz
Output Channels: 16 independent digital output channels
Output Type: Relay output
Isolation: 500V AC isolation
Dimensions: Net dimensions of 73.66 mm (depth) × 358.14 mm (height) × 266.7 mm (width)
Weight: 180g

ABB IMDSO14

Overview

The ABB IMDSO14 is a digital output module specifically designed for industrial automation control systems. It is used to convert digital signals into relay outputs, thereby controlling various on-site devices such as sensors, actuators, and switches. This module features high reliability and stability, enabling it to accurately perform a variety of digital output tasks and meet the requirements of industrial automation systems.

Specifications

Operating Voltage: 220V AC
Output Frequency: 50Hz
Output Channels: 16 independent digital output channels
Output Type: Relay output
Isolation: 500V AC isolation
Dimensions: Net dimensions of 73.66 mm (depth) × 358.14 mm (height) × 266.7 mm (width)
Weight: 180g

Product Features

High Reliability: The module is ruggedly designed to operate stably for long periods in harsh industrial environments.
Flexibility: Each output channel can be configured independently, allowing it to flexibly meet different application requirements.
Signal Isolation: It provides a signal isolation function to protect the control system from interference from on-site devices.
Intelligence: It supports multiple communication protocols, making it easy to integrate with other devices and systems.
Modular Design: It adopts a standard module installation, facilitating maintenance and installation.

Structure and Composition

Structure: The module uses a standard modular design and occupies one slot of the standard INFI 90 OPEN module mounting unit.
Composition: The module includes a Printed Circuit Board (PCB), which is used for digital signal processing and output control.
Installation Method: Standard module installation is supported, and DIN rail mounting (some documents mention 35mm DIN rail mounting) is also available.

Application Fields

Industrial Automation

It is widely used in manufacturing, energy industry, and infrastructure fields, including gas, water supply, sewage treatment, metallurgy, steel manufacturing, hydropower generation, thermal power generation, and papermaking industries.

Industrial Control

It is applied in production line automation, robot control, process control, energy systems, and building management.

Safety Applications

It is used in mechanical protection devices, safety doors and guardrails, emergency stop systems, light curtains, and sensors.

Installation and Maintenance

Installation: The module is installed in the standard INFI 90 OPEN module mounting unit (MMU) and occupies one slot.
Maintenance: The module supports regular maintenance and troubleshooting, with detailed installation and maintenance manuals provided.
Maintenance: It also supports module replacement and troubleshooting, with detailed installation and maintenance manuals provided.
