ABB PFTL101BE 2.0 kN Tension Load Cell (3BSE004214R1)

Product Summary

The ABB PFTL101BE 2.0 kN (3BSE004214R1) is a precision tension load cell designed for accurate force measurement in industrial web-handling and tension control systems. Engineered for continuous operation, it delivers reliable feedback for closed-loop control, helping maintain stable product quality and process efficiency across demanding production environments.

Performance Parameters

Rated Capacity: 2.0 kN

Product Type: Tension Load Cell / Force Sensor

Measuring Principle: Strain gauge-based force measurement

Output: Compatible with ABB tension controllers and amplifiers

Mechanical Design: Robust, low-deflection construction

Environmental Suitability: Industrial production conditions

Product Code: 3BSE004214R1

Key Advantages

High measurement accuracy for stable tension control

Excellent repeatability, even during long production runs

Strong resistance to vibration and mechanical shock

Designed for low sensitivity to off-center loading

Seamless integration with ABB tension control solutions

Mechanical Structure and Design

The PFTL101BE features a compact and rigid mechanical body optimized for mounting in roller systems and tension frames. Its internal strain gauge elements are precisely positioned to ensure accurate force detection while minimizing measurement drift. The housing is built to withstand harsh industrial conditions, providing dependable operation in high-duty cycles.

Industrial Applications

This load cell is widely used in:

Web handling systems for paper, film, and foil processing

Printing, coating, and laminating machines

Converting and packaging production lines

Metal strip and wire processing equipment

Automated manufacturing systems requiring precise tension feedback

Installation Recommendations

The ABB PFTL101BE is designed for straightforward mechanical installation in tension measurement assemblies. Correct alignment and secure mounting are essential to achieve optimal accuracy. It is recommended to follow ABB installation guidelines and ensure proper signal cable routing to avoid electrical interference.

Maintenance and Reliability

The load cell requires minimal maintenance once installed. Periodic inspection of mounting points and cable connections is generally sufficient. Thanks to its solid-state sensing principle and robust construction, the PFTL101BE offers long-term stability with low drift, reducing recalibration frequency.

Additional Information

As an original ABB product, the PFTL101BE 2.0 kN meets strict industrial quality and reliability standards. It is ideal for both new machine designs and system retrofits where precise tension measurement and compatibility with ABB automation platforms are critical.
