ABB 3BHB044356R0001 Capacitive Switch Module

Product Overview

The ABB 3BHB044356R0001 is an industrial‑grade capacitive switch module manufactured by ABB. Unlike high‑power semiconductor modules such as IGBT modules, this component functions as a sensory/control switch that detects capacitance changes and carries a control signal. It is used in control panels, automation systems, and machinery interfaces where precise contact switching is required.

This part is commonly found within larger assemblies and electrical panels as a reliable ancillary peripheral, rather than as a main power conversion device.

Technical Parameters

Here’s a quick technical snapshot based on available reference data:

Model Number: 3BHB044356R0001

Manufacturer: ABB

Type: Capacitive Switch / Control Sensor

Rated Current: ~200 mA

Contact Rating: 10–36 V DC

Switch Type: Capacitive contact

Typical Use: Control signal switching in control panels and automation systems

Mounting Form: PCB/Panel mount or integrated into control kits

Protection & Durability: Designed for industrial electrical environments with stable switching behavior

Application Voltage Range: Low voltage DC applications

Physical Form: Compact switch element for OEM usage

Environmental Tolerance: Typical industrial switch operating tolerance for temperature and humidity

Functional Description

This switch module acts as a capacitive signal switch, meaning it detects electrical changes in circuit conditions and toggles a control output accordingly. It is suitable for applications where robust and stable switching under varying industrial conditions is required.

Capacitive switches are often preferred over mechanical switches in industrial automation due to their resistance to wear and vibration, as well as their ability to sense without requiring large mechanical contact displacement.

Structure and Components

The 3BHB044356R0001 module typically includes:

Capacitive sensing element: Detects voltage or environmental changes

Contact terminals: For DC control signal switching

Insulated housing: Provides electrical isolation and mechanical protection

Connector or pin interface: For mounting on panel or PCB

This compact assembly is designed for robust installation inside control panels and machines.

Applications

The 3BHB044356R0001 switch module is used in:

Industrial control panels and automation cabinets

Machine electrical control interfaces

Low‑voltage DC signal switching

Sensor integration in automation systems

Auxiliary switching operations in PLC or relay logic environments

Because of its low current rating and stable switching characteristics, it’s ideal as a control element rather than a power‑handling device.

Maintenance and Inspection

This control switch requires minimal maintenance. Regularly check:

Loose wiring or terminal corrosion

Functionality via signal switching tests

Cleanliness of contacts and environment

Benefits

Compact and reliable control signal switching

Resistant to mechanical wear and vibration

Industrial‑grade stability

Suitable for low‑voltage DC applications

Conclusion

The ABB 3BHB044356R0001 Capacitive Switch Module is a dependable control‑oriented component used in industrial electrical systems for signal switching and automation control tasks. Its simple yet robust design provides stable and reliable switching behavior for DC control circuits in demanding industrial settings.
