ABB PPD113B03-23-100110 3BHE023584R2334 Process Control Module (AC 800PEC)
Overview
The ABB PPD113B03-23-100110 3BHE023584R2334 is a high-performance process control module belonging to ABB’s AC 800PEC platform. It is designed for demanding real-time automation and power electronics applications, combining fast processing capability with flexible communication and expansion options. This module acts as a core controller in systems requiring high-speed signal processing and precise control logic execution.
Structure & System Architecture
The module integrates multiple functional layers into a compact hardware design:
High-performance CPU (PowerPC architecture) for deterministic control execution
FPGA-based processing layer enabling ultra-fast task handling (nanosecond level)
Integrated communication interfaces including Ethernet and serial ports
Expansion capability via PCI mezzanine modules for customized system integration
This architecture allows the controller to handle multi-level tasks ranging from ultra-fast signal processing to standard control operations.
Technical Specifications
| Parameter |
Description |
| Model |
PPD113B03-23-100110 / 3BHE023584R2334 |
| Manufacturer |
ABB |
| Product Type |
Process Control Module |
| Platform |
AC 800PEC |
| Processor |
PowerPC 750CXe @ 400 MHz |
| Memory |
512 MB RAM, 64 MB Flash |
| Communication |
2× Ethernet, RS-232 service port |
| Power Supply |
24 V DC (dual redundant inputs) |
| Power Consumption |
Approx. 28 W |
| Expansion |
PCI Mezzanine slot |
| Redundancy |
Hot-standby supported |
| Operating Temperature |
-25°C to +70°C |
| Safety Certification |
SIL 2 (IEC 61508) |
| MTBF |
~450,000 hours |
Key Features
Deterministic Real-Time Performance with cycle times down to microseconds
High-Speed Processing Capability leveraging FPGA and CPU integration
Redundant System Support ensuring high availability (>99.999%)
Flexible Communication Options (Modbus TCP, IEC 61850, Profibus, etc.)
Scalable Architecture allowing system expansion via optional modules
Industrial-Grade Reliability with conformal coating and robust design
Functional Description
The PPD113 module serves as a central controller within automation systems, executing:
Advanced control algorithms (PID, sequence control)
High-speed signal acquisition and processing
Communication with field devices and supervisory systems
Safety and interlock logic for critical processes
Its ability to manage multi-speed tasks makes it ideal for applications requiring both fast response and high precision.
Application Areas
This module is widely used in industries where high-speed control and reliability are essential:
Power generation and excitation systems
High-voltage inverter and drive systems
Oil & gas and petrochemical plants
Water treatment and infrastructure automation
Substation and grid control systems
Installation & Integration
The module is designed for integration into ABB AC 800PEC racks and systems. Key installation points:
Ensure stable 24V DC power supply (preferably redundant)
Configure communication interfaces according to system architecture
Install expansion modules if additional I/O or communication is required
Verify redundancy setup for mission-critical applications
Maintenance & Reliability
To maintain optimal performance:
Regularly monitor diagnostic parameters and system logs
Inspect connectors and communication ports
Ensure proper cooling and ventilation
Update firmware through ABB engineering tools when required
Additional Advantages
The ABB PPD113B03-23-100110 3BHE023584R2334 stands out for its combination of ultra-fast processing, scalability, and high reliability. It is especially suitable for advanced automation and power electronics systems where performance and safety are critical.
