Product Introduction

The ABB PPD113B03R2056 is an AC 800PEC controller designed for demanding industrial automation and power-control applications. It is associated with ABB Ident. No. 3BHE023584R2056 and is listed as a Power Processor Module for the AC 800PEC control platform. Available references also identify the controller with a 30K FPGA configuration.

The AC 800PEC platform is designed for applications that require fast processing and precise control. As a result, the PPD113B03R2056 can serve as an important processing element within a larger ABB automation or power-electronics control architecture.

Identification Details

Rather than treating the PPD113B03R2056 as a conventional variable-frequency drive, it is more appropriate to identify it as an AC 800PEC controller / power processor module. Multiple parts references consistently associate the model with this controller family.

Basic identification:

• Brand: ABB
• Type: PPD113B03R2056
• ABB Ident. No.: 3BHE023584R2056
• System: AC 800PEC
• Component Type: Power Processor / Controller
• Processing Technology: FPGA
• FPGA Reference: 30K
• Application: Industrial control and power electronics

The associated 3BHE023584R2056 identification is particularly useful when checking replacement inventory, because ABB equipment may be referenced by either the type designation or the identification number.

Processing and Control Role

The PPD113B03R2056 is intended for applications where control processing speed and deterministic operation are important. Its FPGA-based architecture provides a hardware-oriented processing approach that is suitable for demanding control tasks.

Within an AC 800PEC-based system, the controller can participate in real-time control functions and coordinate control logic with other system components. This makes it suitable for applications where conventional general-purpose PLC processing may not provide the required control performance.

Because the exact system configuration varies by application, the complete control architecture should be checked before replacing the module.

Where It Can Be Used

ABB AC 800PEC controllers are associated with industrial automation and power-control applications. Typical application environments may include:

• Power electronics
• Industrial drives and converters
• Energy systems
• Manufacturing equipment
• High-speed control applications
• Process automation
• Industrial power-control systems

The PPD113B03R2056 should be selected according to the original equipment configuration rather than solely by physical appearance.

Replacement Considerations

When replacing an ABB PPD113B03R2056, accurate identification is essential. First, compare the complete type designation and ABB identification number. Next, check the hardware revision and the surrounding control-system configuration.

It is also recommended to verify:

1. Original ABB part number
2. Identification number 3BHE023584R2056
3. Hardware revision
4. AC 800PEC system configuration
5. FPGA and controller configuration
6. Connector and mounting arrangement
7. Existing firmware or application requirements

Furthermore, a replacement controller should be installed according to the applicable ABB maintenance procedure. After installation, the system should be checked for communication, configuration, and control functionality before being returned to normal operation.

Why Choose ABB PPD113B03R2056?

The ABB PPD113B03R2056 is a specialized AC 800PEC control component rather than a generic automation module. Its processor-oriented architecture and FPGA-based design make correct part-number matching especially important for system maintenance.

For customers maintaining existing ABB automation and power-control systems, sourcing the correct PPD113B03R2056 can help reduce troubleshooting time and avoid unnecessary system modifications.

We supply ABB PPD113B03R2056 / 3BHE023584R2056 for industrial automation maintenance, replacement, and system refurbishment. Please confirm the complete part number and hardware revision when requesting this component so that compatibility can be checked accurately.
