ABB DI810 3BSE008508R1

The ABB DI810 3BSE008508R1 is a digital input module manufactured by ABB, designed primarily for industrial automation systems to collect and process digital signals from external devices.

Channel Configuration

The DI810 module typically provides 16 digital input channels, which can be divided into two groups of 8 channels each, featuring independent isolation design to enhance noise immunity.
Some sources mention 8 channels, but more evidence supports a 16-channel configuration.

-

Input Voltage & Current

• Input voltage range: 24V DC (some sources indicate support for 18–30V DC).
• Input current: 6mA (maximum 150mA).

-

Isolation & Protection

• The module employs a dual-group isolation design, with 8 channels per group, and an isolation voltage of up to 500V AC.
• Protection rating: IP20, making it suitable for industrial environments.

-

Dimensions & Weight

• Dimensions: 115 x 10.5 x 4.5 cm (L x W x H).
• Weight: Approximately 0.2 kg.

-

Compatible Systems & Applications

The DI810 module is compatible with ABB’s S800 and ACS800 series control systems and is widely used in:

• Industrial automation
• Process control
• Machine control
  It receives digital signals from devices such as sensors and switches, converting them into signals processable by PLCs.

-

Additional Features

• Modular design for easy installation and maintenance.
• Each channel includes an LED indicator for input status monitoring.
• Supports hot-swapping, allowing module replacement or addition without system shutdown.
