ABB NTAC-02 58967441E

Product Type & Functionality

The NTAC-02 is a pulse encoder interface module designed to convert mechanical quantities (such as angular displacement and angular velocity) into electrical pulse signals and provide digital output for communication and control with a host system.

It supports multiple encoder types, including incremental and absolute encoders, and offers high precision and reliability. It is ideal for applications requiring accurate position and speed control, such as robotics, machine tools, and automated production lines.

-

Technical Specifications

• Operating Voltage: 24 VDC
• Maximum Signal Frequency: 100 kHz
• Logic Threshold:
  • With 15V encoder supply: "1" > 7.6V, "0" < 2.2V
  • With 12V encoder supply: "1" > 12V, "0" < 2.2V
• Speed Feedback Resolution: 0.00305% (15-bit)
• IP Rating: IP20

-

Application Scenarios

The NTAC-02 is widely used in industrial automation, including:

• Robotic control
• Position and speed control in machine tools and packaging machinery
• Valve positioning and conveyor belt control in process automation
• Motion control for servo-driven motors

-

Installation & Compatibility

• Mounting Method: Standard DIN rail installation
• Compatibility: Compatible with ABB ACS800 series frequency converters
