ABB 3BHL000986P0006
The ABB 3BHL000986P0006 is an inverter control panel under the ABB ACS 800 Series, specifically designed for industrial motor drives and process control. Serving as the human-machine interface (HMI) for the ACS 800 inverter, this control panel provides functions including parameter setting, status monitoring, fault diagnosis, and manual operation. It is suitable for speed control of equipment such as fans, pumps, and compressors.
Core Values of 3BHL000986P0006
Intuitive Operation: Equipped with a high-resolution LCD display and key navigation, it simplifies on-site commissioning.
Real-Time Monitoring: Displays key parameters such as current, frequency, and speed, and supports fault record query.
Portable Design: Features a pluggable structure, allowing shared use across multiple inverters.
Product Parameters
Product Model: 3BHL000986P0006
Manufacturer: ABB
Product Type: Inverter Control Panel (Human-Machine Interface)
Compatible Products: ACS 800 Series Inverters
Display Screen: 4-line backlit LCD (128×64 pixels)
Operation Method: Key navigation (function keys + direction keys)
Communication Interface: Fiber optic interface (for connection to the inverter)
Supported Languages: Multilingual (English, Chinese, German, etc.)
Storage Function: Saves parameter settings and fault history
Operating Temperature Range: 0°C to +50°C (32°F to +122°F)
Protection Class: IP20 (must be installed in a control cabinet)
Power Supply: Powered by the inverter via fiber optic cable
Certification Standards: CE, UL
Structure and Composition
The 3BHL000986P0006 adopts a compact design, with main components including:
LCD Display Module: A 4-line backlit LCD screen that shows parameters, status, and alarm information.
Key Panel: Includes navigation keys (up, down, left, right), function keys (F1-F4), confirm key, and cancel key.
Communication Interface: A fiber optic interface that communicates with the inverter main board and resists electromagnetic interference.
Microcontroller: Processes user input, refreshes the display, and manages data storage.
Housing: Made of plastic, lightweight and durable, suitable for handheld operation.
Main Features and Advantages
User-Friendly Operation
Multilingual interface supports quick switching, adapting to global deployment.
Clear menu navigation structure, with parameters grouped by function (e.g., motor parameters, control parameters).
Real-Time Monitoring and Diagnosis
Displays real-time data (such as output current, frequency, and power).
Stores the last 10 fault records with timestamps and fault values, facilitating problem troubleshooting.
Portability and Shared Use
Pluggable design allows one control panel to be used with multiple ACS 800 inverters, reducing costs.
Fiber optic communication isolates high-voltage noise, ensuring secure data transmission.
Industrial-Grade Reliability
Wide temperature operation range (0°C to +50°C) to adapt to workshop environments.
Anti-static design (ESD protection) to prevent damage during operation.
Application Fields
The 3BHL000986P0006 is mainly used in the following scenarios:
HVAC Systems: Speed control and energy management of fans and pumps.
Manufacturing Industry: Speed adjustment of conveyors and mixers.
Water Treatment: Flow control and monitoring of pump stations.
Typical Application Case
In central air conditioning systems, the 3BHL000986P0006 is used to set the fan speed curve of the ACS 800 inverter, enabling on-demand air supply and achieving energy savings of over 30%.
Related Products
ACS 800-04: ACS 800 inverter cabinet unit (for matching use)
ACS 800-01: ACS 800 inverter standalone unit (for matching use)
3BHE039203R0101: ACS 800 backup control panel
Installation and Maintenance
Installation Key Points
Insert the control panel into the inverter’s fiber optic interface; a "click" sound indicates a secure connection.
Prevent contamination or scratches on the fiber optic interface, and clean it regularly with anhydrous alcohol.
Maintenance Recommendations
Regularly back up parameters (via the control panel’s storage function).
Avoid plugging or unplugging the control panel when the power is on.
