The ABB AO810V2 (3BSE038415R1) is a high-reliability Analog Output Module designed for ABB distributed control systems. It is primarily used to convert digital control signals into precise analog outputs, enabling accurate control of actuators, valves, and other field devices. With its robust design and stable output performance, this module is well suited for continuous industrial operation.

Functional Characteristics

The AO810V2 provides multiple independent analog output channels, allowing precise regulation of process variables. It supports smooth signal transmission and is optimized for integration into ABB automation architectures, ensuring seamless communication with controllers and I/O subsystems.

Its design emphasizes accuracy, repeatability, and long-term stability, which are essential in process automation environments.

Technical Data

Product Type: Analog Output Module

Model: AO810V2

Part Number: 3BSE038415R1

Number of Channels: 8 analog output channels

Output Signal Types: Voltage or current (configuration-dependent)

Resolution: High-resolution digital-to-analog conversion

System Compatibility: ABB industrial control and DCS platforms

Operating Conditions: Industrial-grade temperature and EMC tolerance

Design and Internal Structure

The module features a compact, plug-in design with clearly defined channel separation. Internal circuitry includes digital-to-analog converters, signal conditioning components, and protective elements to ensure stable output even in electrically noisy environments.

The modular construction allows easy replacement and expansion while maintaining system integrity.

Typical Application Fields

Process automation and control systems

Chemical, oil and gas, and power generation plants

Flow, pressure, and temperature control loops

Actuator and valve position control

Industrial retrofitting and system expansion projects

Installation and Service

Installation is performed by inserting the AO810V2 into its designated I/O slot within the ABB system. Proper configuration through the control software is required to define output ranges and channel behavior.

Maintenance requirements are minimal. Regular system diagnostics and occasional inspection are usually sufficient to ensure long-term, trouble-free operation.

Additional Benefits

High signal accuracy and repeatability

Seamless integration with ABB automation platforms

Supports reliable control in critical industrial processes

The ABB AO810V2 3BSE038415R1 Analog Output Module is a dependable choice for engineers seeking precise analog control, modular flexibility, and proven ABB industrial quality in demanding automation environments.
